Hexode / triode
|
|
Introduced in 1936
|
| 1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
tc |
base |
| m |
f |
a |
g2,g4 |
g(t),g1 |
a(t) |
f |
k |
g3 |
octal |
| hexode |
Vf |
Af |
Va |
Vs |
Vg |
mAa |
mAs |
ra |
gm |
Pdiss |
| |
6.3 |
0.3 |
250 |
100 |
-3 |
2.5 |
6 |
600,000 |
0.36 |
0.75 |
| triode |
Va |
mAa |
gm |
Pdiss |
| |
100 |
3.8 |
3 |
0.75 |
| Equivalent |
6K8GT, CV1944, CV1945, CV1946, VT167 |
|
|
|
