.jpg)
|
| 1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
base |
| s,nc |
-f |
a |
g2 |
g1 |
- |
f+ |
fct |
octal |
Beam power pentode for battery
receivers
with central tap for 1.4V, 0.1A
Introduced in 1939
|
Vf |
Af |
Va |
Vs |
Vg |
mAa |
mAs |
ra |
gm |
Pout |
|
2.8 |
0.05 |
90 |
90 |
-4.5 |
9.5 |
2.2 |
90,000 |
2.2 |
0.27 |
| Equivalent |
DL33, N15, N16, VT221 |
|
