Double triode / pentode
| 1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
11 |
12 |
base |
|
f |
g1 |
g2 |
k(p),g3,is |
kt(2),is |
a(t2) |
k(t1) |
g(t2) |
a(t1) |
g(t1) |
a(p) |
f |
Decar 12 |
| |
Vf |
Af |
Va |
Vs |
Vg |
mAa |
mAs |
ra |
Pdiss |
| pentode |
14.2 |
0.45 |
135 |
135 |
-` |
17 |
4 |
45,000 |
4 |
| triode 1 |
|
|
200 |
|
-2* |
7 |
|
12,400 |
1.5 |
| triode 2 |
|
|
200 |
|
-~ |
9.2 |
|
9,400 |
2 |
| `) -6.0 at mAa = 100
|
| *) -5.5 at mAa = 100 |
| ~) -6.5 at mAa = 100 |
|
|
|
