Battery charger
Rectifier used for charging 1-3 storage cells. Input voltage 220 volts. Recommended tubes: Philips 451 and 452.
Data                                         Valves
Serial number: 283
Made in: 1929
Purchased in: 2013
Circuit 1
  Circuit 2
Side view
